Lenze 8200 - Page 191

Configuration
8200SHB0199
7-53
7.5.14.2 Priority mask for digital inputs
Only “HVAC” controllers
Code Name
Possible settings
IMPORTANT
Lenze Choice Info
C115¤ Priority mask digital
inputs
-0- E4 E3 E2 E1
-0-0 000
-1-0 001
-2-0 010
-3-0 011
-4-0 100
-5-0 101
-6-0 110
-7-0 111
-8-1 000
-9-1 001
-10- 1 0 1 0
-11- 1 0 1 1
-12- 1 1 0 0
-13- 1 1 0 1
-14- 1 1 1 0
-15- 1 1 1 1
0: Function Ex
depends on C001
1: Function Ex is
independent of C001
Function - Independently of the operating mode C001 = -3- (control via LECOM), it is possible to activate
additional digital inputs.
- It is now possible to use additional control functions via terminals E1 ... E4. The signals are
assigned by means of an ORlink.
- C115 = -0- is always active with terminal configuration (C007)with manual/remote changeover.
Adjustment Example
The DC injection brake is to be activated via terminal 3:
- Operating mode C001 = -3- (control via LECOM).
- Terminal configuration C007 = -0-.
Solution:
- Set the prioritymask C115 = -4-
- The DC injection brake can now be activated via terminal E3.
Important
- Controller inhibit and TRIP reset always have priority.
- With C115 = -0-, alsoTRIP set and QSP have priority.
