Lenze 8200 - Page 193

Configuration
8200SHB0199
7-55
7.5.14.4 Quick stop QSP
Setting range 820X
Code Name
Possible settings
IMPORTANT
Lenze Choice Info
C013 Deceleration time T
if
820X 5.00 0.00 {0.05 s} 999.00
Setting range 821X/822X/824X
Code Name
Possible settings
IMPORTANT
Lenze Choice Info
C105 Deceleration time
quick stop
821X/822X/824X
5.00 0.00 {0.02 s} 999.00
0.00 {0.02 s} 1300.00 HVAC only
Function
820X If youactivate the function quick stop, the drive will be decelerated to standstill over the set
deceleration time (C013). If the value falls below f
d
= 0.1Hz, the DC-injection brake (DCB) will be
activated.
821X/822X/824X The activation of quick stop decelerates the drive to standstill according tothe deceleration time set
und C105. If f
d
falls below the threshold C019, the DC-injection brake (DCB)will be activated.
Activation
Series “Standard”:
Series “HVAC”:
- C007 = -14- ... -22-:
- LOWlevel at terminals E3 and E4
- HIGH level at terminals E3 and E4 when switching on the mains
- C007 = -2-, -4-, -8-, -9-, -13-:
-LOWlevelatterminalE3
- C007 = -14- ... -22-, -34-, -47-:
- LOWlevel at terminals E3 and E4
- HIGH level at terminals E3 and E4 when switching on the mains
- C007 = -46-, -49-:
-LOWlevelatterminalE2
- C007 = -2-, -4-, -8-, -9-, -13-, -30-, -31-, -32-, -36-, -37-, -40-, -43-, -45-:
-LOWlevelatterminalE3
- C007 = -33-, -42-:
-LOWlevelatterminalE4
The signal levels are indicated for C114 = -0- (see chapter 7.5.14.1).
Special features
821X/822X/824X
Series “HVAC”:
- Independently of the operating mode C001, quick stop can always be activated via terminals.
- The activation of quick stop via terminals can be switched-off with the priority mask (C115).
- Quick stop acts on the main setpoint only. Quick stop does not have an effect on the additional
setpoint (C049)and the correction value of the process controller (software level 3.0).
