Lenze 8200 - Page 224

Configuration
8200SHB01997-86
Code IMPORTANTPossible settingsNameCode IMPORTANT
InfoChoiceLenze
Name
C003¤ Save parameter set -1- -0- Data will not be saved on EEPROM;
all data will be lost when switching
off the mains
-1- Data will be saved on EEPROM;
setting when switching on the
mains
Page 7-8 -0- only valid for
C010, C011, C012,
C013, C037, C038,
C105, C181 and
C182
C004¤ Switch-on display -0- -0- Field frequency f
d
-1- Unit load
-2- Motor current
Page 7-62
C005¤ Configuration -0- -0- Operation with open-loop control
via terminal 8
-1- Operation with open-loop control
via terminal 8 with setpoint
summation via frequency input E1
-2- Operation with open-loop control
via frequency input E1 with setpoint
summation via terminal 8
Page 7-26,
7-61
If C005 = -0-
- 2mscycletime
If C005 = -1- ... -7-
- 4mscycletime
C005 = -4-, -5- not
applicable
-3- Open loop operation via frequency
input E1 with limitation of the
apparent motor current via
terminal 8
C005 = -3-
with
C014 = -2-, -4-
possible
-6- Operation with closed-loop control;
setpoint via terminal 8 with digital
frequency feedback via terminal E1
-7- Operation with closed-loop control,
setpoint via frequency input E1 with
analog feedback via terminal 8
C007¤ Te r mi n a l
configuration
-0- E4 E3 E2 E1
-0- CW/CCW GSB JOG1/2/3
-1- CW/CCW PAR JOG1/2/3
-2- CW/CCW QSP JOG1/2/3
-3- CW/CCW PAR GSB JOG1
-4- CW/CCW QSP PAR JOG1
-5- CW/CCW GSB TRIP set JOG1
-6- CW/CCW PAR TRIP set JOG1
-7- CW/CCW PAR GSB TRIP set
-8- CW/CCW QSP PAR TRIP set
-9- CW/CCW QSP TRIP set JOG1
-10- CW/CCWTRIP set UP DOWN
Page 7-10,
7-44, 7-46,
7-50, 7-54,
7-58,
- R=
CWrotation
- L=
CCWrotation
- GSB =
DC-injection brake
- PAR =
Parameter set
changeover
- JOG =
Fixed frequency
- QSP =
Quick stop
