Installation
8200SHB01994-2
Possible mounting positions for types 8201 to 8214
- In vertical position at the back of the control cabinet, terminals point to the
front:
- With attached fixing rails.
- With special fixing unit on one or two DIN rails.
- Turned by 90 (flast assembly on the backside of the control cabinet):
- Insert the attached fixing rail into the guides at the heat sink.
- Horizontally with an additional fan.
- On a pivoting frame for assembly depths < 198 mm:
- Therefore easy handling and installation of the front interfaces possible.
Possible mounting positions for types 8215 to 8218
- In vertical position at the back of the control cabinet, terminals point to the
front:
- With attached fixing rails.
- Thermally separated with external heat sink (”push-through technique”).
- Variant V003 thermally separated with external cooler in ”Cold plate”
technique (e.g. with convection cooler).
Possible mounting positions types 822X/824X
- In vertical position at the back of the control cabinet, terminals point to the
front:
- With attached fixing brackets.
- Thermally separated with external heat sink (”push-through technique”).
- Variant V003 thermally separated with external cooler in ”Cold plate”
technique (e.g. with convection cooler).
