Lenze 8200 - Page 97

Installation
8200SHB0199
4-39
Protection against polarity reversal
- The protection against polarity reversal prevents the wrong connection of
the internal control inputs. It is however possible to overcome the protection
against polarity reversal by applying great force.
Overview
820X/821X 822X/824X
62
7
8
9
K11
K12
K14
20
28
E1
E2
E3
E4
39
K21
K22
K24
62
7
8
9
K11
K12
K14
20
28
E1
E2
E3
E4
39
K21
K22
K24
FIG 4-23 Layout of the control terminals
