9.10 EtherCAT 383
9.10.1 Device idencaon 384
9.10.2 EtherCAT conguraon 385
9.10.3 LED status displays 386
9.10.4 Diagnoscs 386
9.10.5 Monitoring 387
9.10.6 Objects 388
9.10.7 Process data transfer 389
9.10.8 Parameter data transfer 393
9.10.9 Short setup 394
9.11 POWERLINK 396
9.11.1 Introducon 396
9.11.2 Basic sengs 397
9.11.3 LED status displays 398
9.11.4 Diagnoscs 399
9.11.5 Process data transfer 399
9.11.6 Monitoring 400
9.11.7 Error response 400
9.11.8 Supported objects 400
9.11.9 Short setup 406
10 Conguring the process controller 407
10.1 Basic process controller sengs 408
10.2 Process controller - idle state and rinse funcon 414
10.2.1 Process controller idle state 414
10.2.2 Process controller rinse funcon 416
