9.6 PROFIBUS 294
9.6.1 Introducon 294
9.6.2 Communicaon me seng 294
9.6.3 Staon address seng 295
9.6.4 Baud rate seng 296
9.6.5 Monitoring 296
9.6.6 LED status displays 298
9.6.7 Diagnoscs 298
9.6.8 Funcons 299
9.6.9 Data mapping 300
9.6.10 Parameter data transfer 303
9.6.11 Read parameter data 305
9.6.12 Write parameter data 308
9.6.13 Error codes for parameter data transfer 311
9.6.14 Restart communicaon 312
9.6.15 Short setup 313
9.7 EtherNet/IP 316
9.7.1 Basic sengs 317
9.7.2 Monitoring 320
9.7.3 LED status displays 322
9.7.4 Diagnoscs 322
9.7.5 Objects 324
9.7.6 Restart communicaon 331
9.7.7 Process data transfer 332
9.7.7.1 Customer specic conguraons 337
9.7.8 Parameter data transfer 342
9.7.9 Short setup 346
9.8 Modbus TCP 348
9.8.1 Introducon 348
9.8.2 Basic sengs 349
9.8.3 Time-out behaviour 351
9.8.4 LED status displays 352
9.8.5 Diagnoscs 353
9.8.6 Funcon codes 355
9.8.7 Data mapping 360
9.8.8 Short setup 362
9.8.9 Restart communicaon 363
9.8.10 Baud rate seng 363
9.9 PROFINET 365
9.9.1 Introducon 365
9.9.2 Basic sengs 366
9.9.3 LED status displays 368
9.9.4 Diagnoscs 368
9.9.5 Monitoring 370
9.9.6 Data mapping 371
9.9.7 Parameter data transfer 375
9.9.8 Short setup 377
