Lenze i55AE155F

Parameter Name / value range / [default seng] Info
0x400A:001
(P591.01)
Process output words: NetWordOUT1
(NetWordOUTx: NetWordOUT1)
•
Read only
Mappable data word for the output of status messages of the inverter
via network.
Bit 0 Mapping bit 0 Mappable data word for the output of status messages of the inverter
via network.
Assignment of the status message: 0x2634:010 (P420.10)
Bit 1 Mapping bit 1 Mappable data word for the output of status messages of the inverter
via network.
Assignment of the status message: 0x2634:011 (P420.11)
Bit 2 Mapping bit 2 Mappable data word for the output of status messages of the inverter
via network.
Assignment of the status message: 0x2634:012 (P420.12)
Bit 3 Mapping bit 3 Mappable data word for the output of status messages of the inverter
via network.
Assignment of the status message: 0x2634:013 (P420.13)
Bit 4 Mapping bit 4 Mappable data word for the output of status messages of the inverter
via network.
Assignment of the status message: 0x2634:014 (P420.14)
Bit 5 Mapping bit 5 Mappable data word for the output of status messages of the inverter
via network.
Assignment of the status message: 0x2634:015 (P420.15)
Bit 6 Mapping bit 6 Mappable data word for the output of status messages of the inverter
via network.
Assignment of the status message: 0x2634:016 (P420.16)
Bit 7 Mapping bit 7 Mappable data word for the output of status messages of the inverter
via network.
Assignment of the status message: 0x2634:017 (P420.17)
Bit 8 Mapping bit 8 Mappable data word for the output of status messages of the inverter
via network.
Assignment of the status message: 0x2634:018 (P420.18)
Bit 9 Mapping bit 9 Mappable data word for the output of status messages of the inverter
via network.
Assignment of the status message: 0x2634:019 (P420.19)
Bit 10 Mapping bit 10 Mappable data word for the output of status messages of the inverter
via network.
Assignment of the status message: 0x2634:020 (P420.20)
Bit 11 Mapping bit 11 Mappable data word for the output of status messages of the inverter
via network.
Assignment of the status message: 0x2634:021 (P420.21)
Bit 12 Mapping bit 12 Mappable data word for the output of status messages of the inverter
via network.
Assignment of the status message: 0x2634:022 (P420.22)
Bit 13 Mapping bit 13 Mappable data word for the output of status messages of the inverter
via network.
Assignment of the status message: 0x2634:023 (P420.23)
Bit 14 Mapping bit 14 Mappable data word for the output of status messages of the inverter
via network.
Assignment of the status message: 0x2634:024 (P420.24)
Bit 15 Mapping bit 15 Mappable data word for the output of status messages of the inverter
via network.
Assignment of the status message: 0x2634:025 (P420.25)
0x400B:005
(P592.05)
Process input data: Network setpoint frequency (0.01)
(Process data IN: Net.freq. 0.01)
0.00 ... [0.00] ... 599.00 Hz
Mappable parameter for specifying the frequency setpoint in [0.01 Hz]
via network.
•
The specicaon is made without sign (irrespecve of the rotang
direcon).
•
The rotang direcon is specied via the control word.
•
Example: 456 ≡ 4.56 Hz
0x400C:006
(P593.06)
Process output data: Frequency (0.01)
(Process data OUT: Frequency 0.01)
•
Read only: x.xx Hz
Mappable parameter for the output of the actual frequency value in
[0.01 Hz] via network.
•
The output is eected without sign (irrespecve of the rotang direc-
on).
•
The rotang direcon is specied via the status word.
•
Example: 456 ≡ 4.56 Hz
Conguring the network
PROFINET
Short setup
