Lenze i55AE155F

Details
Encoder dimensioning: Calculate maximum number of increments per revoluon of the encoder
Max. encoder increments = f
max
[Hz] * 60 s / n
max
[rpm]
Max. encoder increment = 100000 [Hz] * 60 s / 1500 [rpm] = 4000 Increments/revoluon
f
max
Maximum input frequency of the digital inputs = 100 kHz = 100000 Hz
n
max
Maximum encoder speed (in this example: 1500 rpm)
Max. encoder increments Maximum number of increments per encoder revoluon
Select an encoder with a maximum number of increments per revoluon which
is lower than or equal to the calculated number. The higher the number of
increments per revoluon, the more stable the system is.
Basic steps for conguring the encoder in the »EASY Starter«:
1.
Set the selecon "HTL encoder (AB) [1]" in 0x2630:002 (P410.02) to congure the digital
inputs DI3 and DI4 as encoder inputs.
2.
Set the encoder increment in 0x2C42:001 (P341.01) according to the manufacturer data/
encoder data sheet.
Parameter Name / value range / [default seng] Info
0x2C42:001
(P341.01)
Encoder sengs: Increments/revoluon
(Encoder sengs: Enc. Inc/Rev)
1 ... [128] ... 16384
•
Seng can only be changed if the inverter is inhibi-
ted.
•
From version 02.00
Encoder increment.
Carry out seng according to manufacturer data/encoder data sheet.
0x2C42:006 Encoder sengs: Actual velocity
•
Read only: x rpm
•
From version 02.00
Display of the speed currently detected by the encoder.
0x2630:002
(P410.02)
Sengs for digital inputs: Input funcon
(DI sengs: Input funcon)
Input funcon of the digital terminals DI3 and DI4.
0 Digital input DI3 = digital input
DI4 = digital input
1 HTL encoder (AB) (from version 02.00) DI3 = HTL input for encoder track B
DI4 = HTL input for encoder track A
2 Pulse train (from version 03.00) DI3 = digital input
DI4 = HTL input for pulse train
3 Pulse train/direcon (from version 03.00) DI3 = HTL input for direcon specicaon; HIGH level = counter-clock-
wise (CCW)
DI4 = HTL input for pulse train
Related topics
4Selecon of setpoint source ^ 148
4Posion counter ^ 493
4HTL input setpoint source ^ 565
