Address Designaon Default seng Category Data type Factor A M
0x230A:003
(P580.03)
CANopen stascs: PDO3 received - (Read only) CANopen U16 1 - -
0x230A:005
(P580.05)
CANopen stascs: PDO1 transmied - (Read only) CANopen U16 1 - -
0x230A:006
(P580.06)
CANopen stascs: PDO2 transmied - (Read only) CANopen U16 1 - -
0x230A:007
(P580.07)
CANopen stascs: PDO3 transmied - (Read only) CANopen U16 1 - -
0x230A:009
(P580.09)
CANopen stascs: SDO1 telegrams - (Read only) CANopen U16 1 - -
0x230A:010
(P580.10)
CANopen stascs: SDO2 telegrams - (Read only) CANopen U16 1 - -
0x230B
(P518.00)
CANopen error counter - (Read only) CANopen U16 1 - -
0x231F:001
(P500.01)
Module ID: Acve module ID - (Read only) general U8 1 P -
0x231F:002
(P500.02)
Module ID: Module ID connected - (Read only) general U8 1 - -
0x2320
(P508.00)
Modbus communicaon No acon/no error [0] Modbus RTU U8 1 - -
0x2321:001
(P510.01)
Modbus sengs: Node ID 1 Modbus RTU U8 1 P -
0x2321:002
(P510.02)
Modbus sengs: Baud rate Automac [0] Modbus RTU U8 1 P -
0x2321:003
(P510.03)
Modbus sengs: Data format Automac [0] Modbus RTU U8 1 P -
0x2321:004
(P510.04)
Modbus sengs: Minimum response me 0 ms Modbus RTU U16 1 P -
0x2322:001
(P511.01)
Acve Modbus sengs: Acve node ID - (Read only) Modbus RTU U8 1 - -
0x2322:002
(P511.02)
Acve Modbus sengs: Acve baud rate - (Read only) Modbus RTU U8 1 - -
0x2322:003
(P511.03)
Acve Modbus sengs: Data format - (Read only) Modbus RTU U8 1 - -
0x2323
(P509.00)
Modbus switch posion - (Read only) Modbus RTU U16 1 - -
0x232A:001
(P580.01)
Modbus stascs: Messages received - (Read only) Modbus RTU U32 1 - -
0x232A:002
(P580.02)
Modbus stascs: Valid messages received - (Read only) Modbus RTU U32 1 - -
0x232A:003
(P580.03)
Modbus stascs: Messages with excepons - (Read only) Modbus RTU U32 1 - -
0x232A:004
(P580.04)
Modbus stascs: Messages with errors - (Read only) Modbus RTU U32 1 - -
0x232A:005
(P580.05)
Modbus stascs: Messages sent - (Read only) Modbus RTU U32 1 - -
0x232B:001 ...
0x232B:024
(P530.01 ... 24)
Modbus parameter mapping: Parameter 1 ... Param-
eter 24
0x00000000 Modbus RTU IDX 1 PH -
0x232C:001 ...
0x232C:024
(P531.01 ... 24)
Modbus register assignment: Register 1 ... Register
24
- (Read only) Modbus RTU U16 1 - -
0x232D
(P532.00)
Modbus vericaon code - (Read only) Modbus RTU U16 1 - -
0x232E:001
(P583.01)
Modbus diagnoscs of last Rx data: Oset 0 Modbus RTU U8 1 - -
0x232E:002
(P583.02)
Modbus diagnoscs of last Rx data: Data byte 0 - (Read only) Modbus RTU U8 1 - -
* Default seng depending on the size. Firmware version 05.00.00.00
Appendix
Parameter aribute list
