Display code Short designaon Default seng Seng range Address Category
└ P117.01 Heatsink temp. x.x °C - (Read only) 0x2D84:001 general
P118.00 Digital inputs - - (Read only) 0x60FD general
P119.00 Keypad status - - (Read only) 0x2DAC general
P120.00 Int. HW states - - (Read only) 0x2DAD general
P121.xx
└ P121.01 PID setpoint x.xx PID unit - (Read only) 0x401F:001 general
└ P121.02 PID process var. x.xx PID unit - (Read only) 0x401F:002 general
└ P121.03 PID status - - (Read only) 0x401F:003 general
P123.00 Mot. i2t ulis. x % - (Read only) 0x2D4F general
P125.xx Inverter diag.
└ P125.01 Acve control - - (Read only) 0x282B:001 general
└ P125.02 Acve setpoint - - (Read only) 0x282B:002 general
└ P125.03 Keypad LCD stat. - - (Read only) 0x282B:003 general
└ P125.04 Drive mode - - (Read only) 0x282B:004 general
└ P125.05 Netw. contr.reg. - - (Read only) 0x282B:005 general
└ P125.06 Netw. setp.reg. - - (Read only) 0x282B:006 general
P126.xx Status words
└ P126.01 Cause of disable - - (Read only) 0x282A:001 general
└ P126.02 Cause of QSP - - (Read only) 0x282A:002 general
└ P126.03 Cause of stop - - (Read only) 0x282A:003 general
└ P126.05 Device status - - (Read only) 0x282A:005 general
P135.xx Device ulisat.
└ P135.04 ixt ulisaon x % - (Read only) 0x2D40:004 general
└ P135.05 Error response Fault [3] Selecon list 0x2D40:005 general
P140.xx Sequencer diag
└ P140.01 Acve Step - - (Read only) 0x2DAE:001 general
└ P140.02 StepTime elapsed x.x s - (Read only) 0x2DAE:002 general
└ P140.03 StepTime remain x.x s - (Read only) 0x2DAE:003 general
└ P140.04 Steps complete - - (Read only) 0x2DAE:004 general
└ P140.05 Steps remain - - (Read only) 0x2DAE:005 general
└ P140.06 Acve sequence - - (Read only) 0x2DAE:006 general
└ P140.07 Acve segment - - (Read only) 0x2DAE:007 general
└ P140.08 SeqTime remain % x % - (Read only) 0x2DAE:008 general
└ P140.09 SeqTime remain x.x s - (Read only) 0x2DAE:009 general
P150.00 Error code - - (Read only) 0x603F general
P151.xx Life-diagnosis
└ P151.01 Operang me x s - (Read only) 0x2D81:001 general
└ P151.02 Power-on me x s - (Read only) 0x2D81:002 general
└ P151.03 CU oper. me x ns - (Read only) 0x2D81:003 general
└ P151.04 Switching cycles - - (Read only) 0x2D81:004 general
└ P151.05 Relay cycles - - (Read only) 0x2D81:005 general
└ P151.06 Short-circ.count - - (Read only) 0x2D81:006 general
└ P151.07 Earthfault count - - (Read only) 0x2D81:007 general
└ P151.08 Clamp acve - - (Read only) 0x2D81:008 general
└ P151.09 Fan oper. me x s - (Read only) 0x2D81:009 general
P155.xx Fault memory
└ P155.00 Error memory - - (Read only) 0x2006:000 general
P190.xx Device data
└ P190.01 Product code - - (Read only) 0x2000:001 general
└ P190.02 Serial number - - (Read only) 0x2000:002 general
└ P190.04 CU rmware ver. - - (Read only) 0x2000:004 general
└ P190.05 CU rmware type - - (Read only) 0x2000:005 general
└ P190.06 CU bootlder ver. - - (Read only) 0x2000:006 general
└ P190.07 CU bootlder type - - (Read only) 0x2000:007 general
* Default seng depending on the size. Firmware version 05.00.00.00
