Lenze i950

5.5 Motor control mode
The inverter supports dierent modes for closed-loop/open-loop motor control.
Parameter
Address Name / seng range / [default seng] Info
0x2C00 Motor control mode
•
Seng can only be changed if the inverter is inhibi-
t
ed.
Selecon of the motor control type.
1 Servoregelung (SC-PSM) This control mode is used for servo control of a synchronous motor.
4Servo control for synchronous motor (SC-PSM) ^ 235
A motor encoder must be connected to the inverter. This motor encoder
serves as a feedback system for engine control.
2 Servo control (SC ASM) This control mode is used for servo control of an asynchronous motor.
4Ser
vo control for asynchronous motor (SC-ASM)^ 236
A motor encoder must be connected to the inverter. This motor encoder
is used as a feedback system for the motor control.
3 Sensorless control (SL PSM) This control type is used for the sensorless control of a synchronous
mot
or.
•
Control mode is possible up to a rated power of 22 kW.
4Sensorless control for synchronous motor (SL-PSM)^ 236
4 Sensorless vector control (SLVC) This control type is used for sensorless vector control of an asynchro-
nous mot
or.
5 Reserved
6 V/f characterisc control (VFC open loop) This control mode is used for the speed control of an asynchronous
motor via a V/f characterisc and is the simplest control mode.
4V/f characterisc control for asynchronous motor (VFC open loop)
^ 237
Supplementary chapters:
•
Chap
ter "Congure feedback system for motor control" describes ho
w to set resolvers or
sine/cosine encoders as motor feedback. ^ 198
•
Chapter "Second feedback system for the techology applicaon" describes how a higher-
level control loop can be used as an actual value feedback applicaon for higher accuracy.
^ 211
The detailed descripon of each motor control type can be found in the chapter "Conguring
the motor control“. ^ 234
Basic
seng
Motor control mode
44
