9400 regenerative power supply module | Parameter setting
"CAN on board" system bus
Parameter data transfer
122 L EDS94ARNExxxx EN 2.3 - 06/2014
6.7.2 User data
Structure of the user data in the parameter data telegram
The following subchapters describe the user data in detail.
1st byte 2nd byte 3rd byte 4th byte 5th byte 6th byte 7th byte 8th byte
Command Index Subindex Data 1 Data 2 Data 3 Data 4
Low byte High byte Low word High word
Low byte High byte Low byte High byte
Note!
User data are displayed in the Motorola format.
Parameter data telegram examples
