9400 regenerative power supply module | Parameter setting
Oscilloscope
User interface
174 L EDS94ARNExxxx EN 2.3 - 06/2014
7.3.4 Status bar
The status messages are displayed in the status bar.
7.3.5 Trigger/cursor settings
Trigger
If the Trigger button has been clicked, the input fields for configuring the trigger conditions
will appear. Selecting the trigger condition
( 177)
Cursor
If you click the Cursor button, you can use a vertical measuring line to read individual
measured values of a selectable channel in the oscillograph. Using a second vertical
measuring line, it is possible to indicate the difference between two measured values.
Reading individual measured values
( 180)
7.3.6 Horizontal settings
Use the Horizontal group box to select the time base and the horizontal position.
Selecting the recording time/sample rate
( 176)
7.3.7 Recording settings
Use the Recording group box to select the sample rate and start recording.
Since the measured data memory has a limited capacity, a compromise must be found
between the sample rate and the recording time that results from the time base
setting.Selecting the recording time/sample rate
( 176)
Group box Meaning
Channel Channel selection
Value Display of the value measured at the position of the active measuring line
Difference Display of the difference between the values measured at the two measuring lines
Input field Meaning
Time base [1/div] Selection of time base
• The current time base setting multiplied by ten results in the recording time.
• Change the time base to stretch or compress measurements that have already been
completed.
Position Selection of the horizontal display position
• The position value can be directly entered into the input field or selected using the arrow
buttons.
• When the arrow buttons are used and the <Ctrl> key is pressed, you can increase the step
size to accelerate the shift.
