9400 regenerative power supply module | Parameter setting
Oscilloscope
User interface
7.3.1 Oscilloscope toolbar
7.3.2 Oscillograph
The oscillograph is used to visualise data records.
 Use the zoom and the automatic scaling function to adjust the representation.
 The measured data represented in the form of interpolated curves can be optionally
shown and hidden, represented in any colour or overlaid with the signal characteristics
of other variables recorded.
7.3.3 Vertical settings
Use the Vertical list field to configure the variables to be recorded.
 Simply click into a field to change the corresponding setting.
Icon Function
Loading/importing a data record
( 183)
Saving/exporting a data record
( 182)
Copying a data record to the clipboard
( 185)
Print oscillogram
Activate zoom function
Adjusting the representation
( 179)
Activate automatic scaling function
Adjusting the representation
( 179)
Delete offline data record
Column Name Meaning
1 - Curve colour for representation in the oscillograph
2 Ch Channel number
3OnOn/off
4 Inv Inversion on/off
5 Variable Selection of variable to be recorded
6UnitScaling
7 1/div Vertical scale factor
8OffsetOffset value
• The offset value depends on the scale factor and is designated by a
dashed line in curve colour at the left edge of the oscillograph.
9 Position Position value
• The position value is independent of the scale factor and designated by a
line at the left edge of the oscillograph.
