Lenze L-force 9400 Series Software Manual

9400 regenerative power supply module | Parameter setting
Regenerative power supply module application
Signal configuration
30 L EDS94ARNExxxx EN 2.3 - 06/2014
3.2 Signal configuration
3.2.1 Device and line interface
If required, the default signal configuration of the control and setpoint inputs of the device
and line interface can be easily reconfigured by parameterising the multiplexer
parameters assigned.
Device interface
Line interface
Signal (Lenze setting) Control input Signal configuration
DIGIN 1  Set controller inhibit
(inhibit regenerative feedback)
C03130/1
Control word 1 bit 01  Set controller inhibit
(inhibit regenerative feedback)
C03130/2
DIGIN 3  Reset error 1 C03130/3
Control word 1 bit 07  Reset error 2 C03130/4
Signal (Lenze setting) Control input Signal configuration
DIGIN 2  Activate brake chopper C03190/1
Control word 1 bit 02  Activate brake chopper C03190/2
