Lenze L-force 9400 Series Software Manual

EDS94ARNExxxx EN 2.3 - 06/2014 L 89
9400 regenerative power supply module | Parameter setting
I/O terminals
Overview
5I/O terminals
This chapter provides you with information on possible parameter settings for the input
and output terminals of the regenerative power supply module.
 Tip!
Information on terminal wiring can be found in the Mounting Instructions of the
regenerative power supply module!
5.1 Overview
Front view Terminal assignment Information
"State bus" monitoring function
( 96)
Analog inputs
( 90)
Analog outputs
( 92)
Digital outputs
( 95)
Digital inputs
( 94)
GE
24E
SB
X2
X3
GA
AO1
AO2
A1+
A1-
A1-
A1R
A2+
A2-
GO
24O
DO1
DO2
DO3
DO4
X4
X5
GI
RFR
DI1
DI2
DI3
DI4
DI5
DI6
DI7
DI8
