9400 regenerative power supply module | Parameter setting
I/O terminals
Analog inputs
5.2.2 Parameter setting
Short overview of the parameters for the analog inputs:
5.2.3 Reconfiguring analog input 1 into current input
Proceed as follows to reconfigure analog input 1 into a current input:
1. Jumper terminals A1R and A1 on terminal strip X3 by means of wiring.
2. Select the corresponding current loop under C00034
.
Open-circuit monitoring
Under C00598
you can select an error response to an open circuit for the 4 ...20 mA current
loop.
Parameter Information
C00034
Config. analog input 1
C00598
Resp. to open circuit AIN1
C02730/1
Analog input 1: Gain
C02730/2
Analog input 2: Gain
C02731/1
Analog input 1: Offset
C02731/2
Analog input 2: Offset
C02732/1
Analog input 1: Dead band
C02732/2
Analog input 2: Dead band
C02800/1 Analog input 1: Input signal (-16384 ≡ -100 %, 16383 ≡ 100 %)
C02800/2 Analog input 2: Input signal (-16384 ≡ -100 %, 16383 ≡ 100 %)
Highlighted in grey = display parameter
