Lenze L-force 9400 Series Software Manual

9400 regenerative power supply module | Parameter setting
Parameter reference
Parameter list | C02549
334 L EDS94ARNExxxx EN 2.3 - 06/2014
C02549
C02730
C02731
Parameter | Name:
C02549 | Drive interface: Signals
Data type: UNSIGNED_32
Index: 22026
d
= 560A
h
Display of digital signals of the device interface.
Selection list (display only)
0 FALSE
1 TRUE
Subcodes Information
C02549/1 DI_bSetCInh
C02549/2 Reserved
C02549/3 Reserved
C02549/4 DI_bSwitchOn
C02549/5 Reserved
C02549/6 DI_bReady
C02549/7 DI_bFailActive
C02549/8 DI_bImpActive
C02549/9 DI_bCinhActive
C02549/10 DI_bWarningActive
C02549/11 DI_bUVDetected
C02549/12 DI_bOVDetected
C02549/13 DI_bMainSupplyOk
C02549/14 DI_bReadyToSwitchOn
C02549/15 DI_bOperationEnabled
 Read access  Write access  CINH  PLC STOP  No transfer
Parameter | Name:
C02730 | Analog inputs: Gain
Data type: INTEGER_32
Index: 21845
d
= 5555
h
Setting range (min. value | unit | max. value)
-200.00 % 200.00
Subcodes Lenze setting Information
C02730/1 100.00 % Analog input 1: Gain
C02730/2 100.00 % Analog input 2: Gain
 Read access  Write access  CINH  PLC STOP  No transfer Scaling factor: 100
Parameter | Name:
C02731 | Analog inputs: Offset
Data type: INTEGER_32
Index: 21844
d
= 5554
h
Setting range (min. value | unit | max. value)
-200.00 % 200.00
Subcodes Lenze setting Information
C02731/1 0.00 % Analog input 1: Offset
C02731/2 0.00 % Analog input 2: Offset
 Read access  Write access  CINH  PLC STOP  No transfer Scaling factor: 100
