9400 regenerative power supply module | Parameter setting
Oscilloscope
Technical data
170 L EDS94ARNExxxx EN 2.3 - 06/2014
7 Oscilloscope
The oscilloscope function integrated in the regenerative power supply module can be used
as support for commissioning, maintenance, and troubleshooting.
Typical applications
Graphical representation of any measured values (e.g. speed setpoint, actual speed,
and torque)
Detection of process values without additional measuring instruments (e.g.
oscilloscope, voltmeter, and ammeter)
Convenient documentation for fine tuning of control circuits or parameter changes of
the regenerative power supply module
Documentation of production quality in the context of product liability and quality
assurance
Special features
Recording and saving of the measured values in the regenerative power supply module
Measuring on eight independent channels at the same time
Measuring fast and slow signals by adjustable sample rate
Triggering on channel, variable, or error message
Detecting measured values before and after a trigger event (pre-/post-trigger)
Graphical representation and evaluation of measured values on a PC
Cursor and zoom function for the measurement analysis
Saving & loading of oscilloscope configurations
Exporting measured values via the clipboard for further processing
7.1 Technical data
9400 regenerative power supply module
Memory depth Max. 16384 measured values, depending on the number of channels and the size of
the variables to be recorded.
Memory capacity 32768 bytes
Data width of a channel 1 ... 4 bytes, corresponding to the size of the variables to be recorded
Number of channels 1 ... 8
Trigger level Corresponding to the value range of the variable to be triggered
Trigger selection Immediate triggering, rising/falling edge, signal change
Trigger delay -100 % ... +400 %
Trigger source Channels 1 ... 8, any variable or error message
Max. time base 8 channels 32 bits each ≡ 26 hours
Max. recording time 8 channels 32 bits each ≡ 10 days
