Lenze L-force 9400 Series

9400 regenerative power supply module | Parameter setting
Parameter reference
Parameter list | C00018
276 L EDS94ARNExxxx EN 2.3 - 06/2014
C00018
C00022
C00034
C00050
C00051
C00052
Parameter | Name:
C00018 | Chopper frequency
Data type: UNSIGNED_32
Index: 24557
d
= 5FED
h
Selection list (Lenze setting printed in bold) Information
14 1 kHz fixed Note:
This parameter is only effective in closed-loop operation
(in preparation).
15 2 kHz fixed
16 4 kHz fixed
17 8 kHz fixed
21 2 kHz variable
22 4 kHz variable
23 8 kHz variable
 Read access  Write access  CINH  PLC STOP  No transfer
Parameter | Name:
C00022 | Maximum current
Data type: UNSIGNED_32
Index: 24553
d
= 5FE9
h
Setting range (min. value | unit | max. value) Lenze setting
0.00 A 21474836.47 0.00 A
 Read access  Write access  CINH  PLC STOP  No transfer Scaling factor: 100
Parameter | Name:
C00034 | Config. analog input 1
Data type: UNSIGNED_32
Index: 24541
d
= 5FDD
h
Selection list (Lenze setting printed in bold)
0 -10 ... +10 V
1 -20...-4 mA, +4...+20 mA
2 -20 ... +20 mA
 Read access  Write access  CINH  PLC STOP  No transfer
Parameter | Name:
C00050 | Output power (DC)
Data type: INTEGER_32
Index: 24525
d
= 5FCD
h
Display range (min. value | unit | max. value)
-1000.0 kW 1000.0
 Read access  Write access  CINH  PLC STOP  No transfer Scaling factor: 10
Parameter | Name:
C00051 | Mains frequency
Data type: INTEGER_32
Index: 24524
d
= 5FCC
h
Display range (min. value | unit | max. value)
-800.0 Hz 800.0
 Read access  Write access  CINH  PLC STOP  No transfer Scaling factor: 10
Parameter | Name:
C00052 | Mains voltage
Data type: UNSIGNED_32
Index: 24523
d
= 5FCB
h
Display range (min. value | unit | max. value)
0 V 2147483647
 Read access  Write access  CINH  PLC STOP  No transfer
