EDS94ARNExxxx EN 2.3 - 06/2014 L 293
9400 regenerative power supply module | Parameter setting
Parameter reference
Parameter list | C00309
C00309
C00310
C00311
C00312
Parameter | Name:
C00309 | Service code
Data type: UNSIGNED_32
Index: 24266
d
= 5ECA
h
This code is used internally by the device and must not be overwritten by the user!
Parameter | Name:
C00310 | Service code
Data type: UNSIGNED_8
Index: 24265
d
= 5EC9
h
This code is used internally by the device and must not be overwritten by the user!
Parameter | Name:
C00311 | CAN TPDO1 mask byte x
Data type: BITFIELD_8
Index: 24264
d
= 5EC8
h
A mask can be parameterised for each byte of the TPDO1 in the assigned subcode.
• In case of an event-controlled PDO transmission, only the masked bits will be considered for event control.
• Mask "0x0" means that no bit of the corresponding byte activates the transmission.
• Mask "0xff" means that each bit of the corresponding byte can activate the transmission.
"CAN on board" system bus
Value is bit-coded:
Bit 0 Mask bit 0
... ...
Bit 7 Mask bit 7
Subcodes Lenze setting Information
C00311/1 0x00 Mask for byte 1 ... byte 8 of TPDO1
C00311/...
C00311/8
Read access Write access CINH PLC STOP No transfer
Parameter | Name:
C00312 | CAN TPDO2 mask byte x
Data type: BITFIELD_8
Index: 24263
d
= 5EC7
h
A mask can be parameterised for each byte of the TPDO2 in the assigned subcode.
• In case of an event-controlled PDO transmission, only the masked bits will be considered for event control.
• Mask "0x0" means that no bit of the corresponding byte activates the transmission.
• Mask "0xff" means that each bit of the corresponding byte can activate the transmission.
"CAN on board" system bus
Value is bit-coded:
Bit 0 Mask bit 0
... ...
Bit 7 Mask bit 7
Subcodes Lenze setting Information
C00312/1 0x00 Mask for byte 1 ... byte 8 of TPDO2
C00312/...
C00312/8
Read access Write access CINH PLC STOP No transfer
