Lexmark CS725R Service Manual

Action Yes No
Step 9
Replace the motor (Y developer). See
“Motor (EP drive) removal”
on page 296.
Does the problem remain?
Go to step 10. The problem is
solved.
Step 10
Replace the controller board. See
“Controller board removal” on
page 357.
Does the problem remain?
Contact the next
level of support.
The problem is
solved.
Motor (BOR) service check
Action Yes No
Step 1
Reset the printer.
Does the problem remain?
Go to step 2. The problem is
solved.
Step 2
a Remove the transfer module. See “Transfer module removal”
on page 334.
b Enter the Diagnostics menu, and then navigate to:
Printer diagnostics & adjustments > Motor tests > Black only
retract
c Tou ch Start.
Does the motor run?
Go to step 3. Go to step 5.
Step 3
Manually turn the BOR gear on the transfer module.
Does the gear freely turn?
Contact the next
level of support.
Go to step 4.
Step 4
Replace the transfer module. See
“Transfer module removal” on
page 334.
Does the problem remain?
Go to step 9. The problem is
solved.
Step 5
Check the cable on the motor and on the JBOR1 connector on the
controller board for proper connection.
Is the cable properly connected at both ends?
Go to step 7. Go to step 6.
5028
Diagnostic information
189
