3-2. Opening, closing and locking the doors
Before driving
sitivity of the Hands Free Power Back
Door, such as a pay parking spot, gas sta-
tion, electrically heated road, or fluores-
cent light
O When the vehicle is near a TV tower,
electric power plant, radio station, large
display, airport or other facility that gen-
erates strong radio waves or electrical
noise
O When the vehicle is parked in a place
where objects such as plants are near the
rear bumper
O If luggage, etc. is set near the rear
bumper
O If accessories or a vehicle cover is
installed/removed near the rear bumper
O When the vehicle is being towed
Q Hands Free close & lock (Walk-Away)
function
*1
operating conditions
This function can be operated when all of
the following conditions are met:
O Hands Free close & lock (Walk-Away)
function is enabled
*2
.
O Hands Free Power Back Door
*1
is
enabled.
O An electronic key is not detected within
the vehicle.
O All of the doors other than the back door
are closed.
O The engine switch is in OFF.
O The electronic key is within the effective
range (detection areas).
*1
: If equipped
*2
: These settings must be customized at
your Lexus dealer.
Q Situations in which the Hands Free close
& lock (Walk-Away) function
*1, 2
may
not operate properly
In the following situations, the function may
not operate properly:
O When the smart entry & start system
does not operate properly.
O When the close & lock function does not
operate properly.
O When moving away from the back door
while the Hands Free close & lock (Walk-
Away) function is in the standby state.
O When the number of electronic keys reg-
istered in the vehicle increases.
O When the Hands Free Power Back Door
does not operate properly.
*1
*1
: If equipped
*2
: These settings must be customized at
your Lexus dealer.
Q When reconnecting the battery
To enable the power back door to operate
properly, close the back door manually.
Q If the back door opener is inoperative
The back door can be unlocked from the
inside.
1
Remove the cover.
To prevent damage, cover the tip of the
screwdriver with a rag.
2
Loosen the screw.
3
Turn the cover.
