Lexus LX600 2021 - Checking and Replacing Fuses

566
6-3. Do-it-yourself maintenance
1
Turn the engine switch off.
2
Open the fuse box cover.
X Engine compartment (gasoline
engine)
Type A:
Keep the engine compartment cover
opened or removing the cover (oP.535)
and push the tab in and lift the lid off.
Type B:
Keep the engine compartment cover
opened or removing the cover (oP.535)
and push the tab in and lift the lid off.
X Engine compartment (diesel
engine)
Type A:
Keep the engine compartment cover
opened or removing the cover (oP.535)
and push the tab in and lift the lid off.
Type B:
Keep the engine compartment cover
opened or removing the cover (oP.535)
and push the tab in and lift the lid off.
Type C:
Push the tab in and lift the lid off.
Checking and replacing
fuses
If any of the electrical components
do not operate, a fuse may have
blown. If this happens, check and
replace the fuses as necessary.
Checking and replacing fuses
