2-1. Instrument cluster
Vehicle status information and indicators
Q Locations of gauges and meters
The location of some displayed items and the units of measure may differ depending on the
intended destination of the vehicle.
Engine oil pressure gauge
Displays the engine oil pressure
Outside temperature (oP.122)
Tachometer
Displays the engine speed in revolutions per minute
Speedometer
Displays the vehicle speed
Clock
The GPS clock’s time is automatically adjusted by utilizing GPS time information. For
details, refer to the “Multimedia Owner’s Manual”.
AHC display
Display the status of AHC (Active Height Control Suspension) (oP.409)
Voltmeter
Displays the charge state
Fuel gauge
Displays the quantity of fuel remaining in the tank
Meter display
A
B
C
D
E
F
G
H
