4-5. Using the driving support systems
As the guide lines are shown in the air
near the rear bumper, there are times
that they may look like they are off-
center.
When there are three-dimensional objects (such as vehicle bumpers, etc.) nearby
in positions higher than the surface of the road, take extra care when using the fol-
lowing.
Since the panoramic view, Side Clearance View and Cornering View process and
display images based on flat road surfaces, it cannot depict the position of three-
dimension objects (such as vehicle bumpers, etc.) that are in positions higher than
the surface of the road. For example, even though it appears that there is space
between the bumpers of the two vehicles in the illustration below and they are not
likely to collide, in reality, a collision is about to occur.
Vehicle center estimated course
line
Distortion of three-dimensional objects on the screen
Q Lexus parking assist-sensor pop-up display
When a sensor indicator on the Lexus parking assist-sensor display illuminates in red or a
buzzer sounds continuously, be sure to check the area around the vehicle immediately
and do not proceed any further until safety has been ensured, otherwise an unexpected
accident may occur.
Panoramic view display (including magnified display), Side Clearance View
and Cornering View display
To Next Page
