4-5. Using the driving support systems
Visually check the surroundings and
the area behind the vehicle. In the case
shown below, the truck appears to be
outside of the estimated course lines
and the vehicle does not look as if it hits
the truck. However, the rear body of
the truck may actually cross over the
estimated course lines. In reality if you
back up as guided by the estimated
course lines, the vehicle may hit the
truck.
Estimated course lines
Visually check the surroundings and
the area behind the vehicle. On the
screen, it appears that a truck is park-
ing at point . However, in reality if
you back up to point , you will hit
the truck. On the screen, it appears
that is closest and is farthest
away. However, in reality, the distance
to and is the same, and is
farther than and .
Distance guide lines
A
A
B
