Chapter 1 Product Description
6
QoS
˙ QoS based on rate limit
˙ Classification based on
Outbound direction
Source/destination IP address
Protocol types
Port number range
DSCP
Management
˙ Support SNMP v1/v2
˙ MIB: MIBII, Transmission MIB
˙ Telnet
˙ SSH
˙ HTTP Web-based management
˙ Serial console with CLI, DB9 / RS232
˙ TFTP firmware download
˙ Configuration upload/ download
˙ SNMP/ Telnet via data channel/ In-band Management channel
Administration & Diagnostics
˙ Ping
˙ Trace route
˙ Loopback
Diagnostics Test
Loopbacks For E1/ DS1: Line Loopback, Payload Loopback
For DTE: DTE to DTE Loopback
Test Pattern For E1: 15-bit PRBS, 3-in-24, 1-in-8, 2-in-8, 1:1
For DS1: 20-bit QRSS, 3-in-24, 1-in-8, 2-in-8, 1:1
Idle Channel For E1: Use of idle channel to perform PRBS diagnostic test
For DS1: Use of idle channel to perform QRSS diagnostic test
Performance Monitor
Performance Store Last 24 hours performance in 15-minute intervals and last 7 days in 24-hour summary line, user, and
remote site
Performance Reports
Date & Time, Error Second, Unavailable Second, Burst Error Second, Severe Error Second,
Controlled Slip Second, and Loss of Frame Count
Alarm History Date & Time, Alarm Type, and Location
Alarm Queue Maximum 40 alarm records which record the latest alarm type, location, and date & time
Electrical
AC: Full range support 100 – 240V
DC: -24V or -48V support
Power consumption: Max. 6 watt
Physical
Dimensions 210 x 41.5 x 140 mm. (WxHxD)
Temperature 0 -50°C
Humidity 0-95% RH (NON-CONDENSING)
Mounting Desk-top stackable, wall mount
Compliance
EMC FCC15 Class A EN300 386, EN55022, EN55024
Safety UL60950 ETL/ETLC, IEC60950 CB, EN60950
Network FCC68, CS-03
