12 Before commissioning
12.1 Fasten transportation belt
17716
7 Transportation belt
16 Plastic slides
17 Velcro fastener
 Thread the transportation belt into the welding ma-
chine and plastic slides. See sequence of the num-
bering in the picture.
12.2 Fastening accessories belt
15 1816
15 Accessories belt with fastener
16 Plastic slides
18 Fastener
 Thread the accessories belt into the handle and plas-
tic slides. See sequence of the numbering in the pic-
ture.
 Plug the belt fasteners together.
