LORCH ControlPro T-Series User Manual

Messages
- 55 -
04.19 909.1709.9-05
Technical data* Units
Machine type
T 250 DC
ControlPro
T 300 DC
ControlPro
T 250 AC/DC
ControlPro
T 300 AC/DC
ControlPro
Current input I1 no-load A 0,15 0,15 0,15 0,15
Mains fuse slow-response TIG/EL A 16 16 16 16
Phase angel cos φ I2 max cos φ 0,97 0,97 0,97 0,97
Powerfactor λ at I2 max λ
Max. permissible system impedance Zmax in
acc. with IEC 61000-3-11/-12
mΩ 81 67 76 94
Recommended generator performance kVA > 13 / 3 ~ > 16 / 3 ~ > 13 / 3 ~ > 16 / 3 ~
Machine
Protection class IP 23S 23S 23S 23S
Insulation class B B B B
Cooling method F F F F
Noise emission db(A) < 70 < 70 < 70 < 70
Norm EN 60974-1 EN 60974-1 EN 60974-1 EN 60974-1
Designation CE, S CE, S CE, S CE, S
Dimensions and weights
Dimensions power source (LxWxH) mm 430 x 185 x 326 483 x 185 x 326
Weight of power source kg 14,3 14,5 16,3 16,3
Tab. 9: Technical data
ED = Switch-on duration
*) measured at 40° C environmental temperature
18 Messages
18.1 Informative messages
After the message has been output, the
machine will only function to a limited ex-
tent; the error must be corrected as quickly
as possible.
Code Note Cause Possible remedy
H01 Undervoltage Mains voltage too low Check mains voltage
H03 Fans Fan fault Inform Service
H04 PFC PFC faulty Inform Service
H05 EEProm checksum error Communication with EEProm faulty
Switch machine off and on again, execute
master reset
H06 EEProm write/read error Communication with EEProm faulty
Switch machine off and on again, execute
master reset
H10 Torch protection
Torch doesn’t send ID although torch
protection is activated
Adjust torch-ID
Tab. 10: Informative messages
i
i
