LORCH ControlPro T-Series User Manual

Technical data
- 54 -
04.19909.1709.9-05
Technical data* Units
Machine type
T 250 DC
ControlPro
T 300 DC
ControlPro
T 250 AC/DC
ControlPro
T 300 AC/DC
ControlPro
TIG welding
Welding range min - max
A 5 - 250 5 - 300 5 - 250 5 - 300
V 10,2 - 20,0 10,2 - 22,0 10,2 - 20,0 10,2 - 22,0
Idle voltage (peak value in accordance with
EN 60974-1)
V/DC < 113 < 113 < 113 < 113
Current setting Innitely variable
Slope characteristic falling
Welding current at ED 100% A 175 200 175 180
Welding current at ED 60% A 200 250 200 220
ED at maximum welding current % 35 35 35 30
Current consumption I1 (at ED 100%) A 9,0 9,8 8,6 8,8
Current consumption I1 (at ED 60%) A 10,5 13,5 10,2 11,2
Current input I1 max A 13,5 17,0 13,6 17,1
Maximum effective mains current (I1eff) A 9,0 10,5 8,6 9,4
Power consumption S1 (at ED 100%) kVA 6,2 6,8 6,0 6,1
Power consumption S1 (at ED 60%) kVA 7,3 9,4 7,1 7,8
Input power S1 max kVA 9,4 11,8 9,4 11,8
Electrode welding
Welding range min - max
A 10 - 200 10 - 200 10 - 200 10 - 200
V 20,4 - 28,0 20,4 - 28,0 20,4 - 28,0 20,4 - 28,0
Idle voltage (peak value in accordance with
EN 60974-1)
V/DC < 113 < 113 < 113 < 113
Current setting Innitely variable
Slope characteristic falling
Welding current at ED 100% A 170 170 170 170
Welding current at ED 60% A 185 200 185 200
ED at maximum welding current % 55 60 55 60
Current consumption I1 (at ED 100%) A 10,7 12,3 10,7 11,6
Current consumption I1 (at ED 60%) A 11,5 14,4 11,5 13,9
Current input I1 max A 12,5 14,4 12,5 13,9
Maximum effective mains current (I1eff) A 10,7 12,3 10,7 11,6
Power consumption S1 (at ED 100%) kVA 7,4 8,5 7,4 8,0
Power consumption S1 (at ED 60%) kVA 8,0 10,0 8,0 9,6
Input power S1 max kVA 8,7 10,0 8,7 9,6
Weldable electrodes mm 1,5 - 5,0 1,5 - 5,0 1,5 - 5,0 1,5 - 5,0
Mains
Mains voltage V 400/ 3~ 400/ 3~ 400/ 3~ 400/ 3~
Mains frequency Hz 50 - 60 50 - 60 50 - 60 50 - 60
Positive mains tolerance % 15 15 15 15
Negative mains tolerance % 15 15 15 15
max. negative network tolerance with reduced
power output
25 25 25 25
Mains connection mm
2
4 x 1,5 4 x 1,5 4 x 1,5 4 x 1,5
Mains plug CEE 16 CEE 16 CEE 16 CEE 16
