LORCH ControlPro T-Series User Manual

Technical data
- 53 -
04.19 909.1709.9-05
Technical data* Units
Machine type
T 180 DC
ControlPro
T 220 DC
ControlPro
T 180 AC/DC
ControlPro
T 220 AC/DC
ControlPro
Mains
Mains voltage V 230 / 1~ 230 / 1~ 230 / 1~ 230 / 1~
Mains frequency Hz 50 - 60 50 - 60 50 - 60 50 - 60
Positive mains tolerance % 15 15 15 15
Negative mains tolerance % 15 15 15 15
Mains connection mm
2
3 x 2,5 3 x 2,5 3 x 2,5 3 x 2,5
Mains plug Schuko Schuko Schuko Schuko
Current input I1 no-load A 0,26 0,26 0,26 0,26
Mains fuse slow-response TIG/EL A 16 16 16 16
Phase angel cos φ I2 max cos φ 0,97 0,99 0,97 0,99
Powerfactor λ at I2 max λ 0,61
Max. permissible system impedance Zmax in
acc. with IEC 61000-3-11/-12
mΩ 23 140 23 140
Recommended generator performance kVA > 6,0 / 1~ > 6,0 / 1~ > 6,0 / 1~ > 6,0 / 1~
Machine
Protection class IP 23S 23S 23S 23S
Insulation class F F F F
Cooling method F F F F
Noise emission db(A) < 70 < 70 < 70 < 70
Norm EN 60974-1 EN 60974-1 EN 60974-1 EN 60974-1
Designation CE, S CE, S CE, S CE, S
Dimensions and weights
Dimensions power source (LxWxH) mm 430 x 185 x 326 483 x 185 x 326
Weight of power source kg 12,2 12,3 13,3 13,4
Tab. 8: Technical data
ED = Switch-on duration
*) measured at 40° C environmental temperature
