5. INSPECTION AND MAINTENANCE
5.1 LEGAL INSPECTION
If a periodic safety inspection is required by the laws and regulations of your country, perform that inspection in
addition to the inspection items listed below.
1. Verify that all safety devices are operating properly.
2. Check the hoist accessories, including the hook block, for problems or damage.
3. Check the structural parts of the machine, including the frame and boom, for cracks, deformation and damage.
4. Check for loose or missing mounting bolts and joints.
5. Verify that the boom operates properly by stopping, extending, retracting, raising, lowering and swinging the
boom.
Contact Maeda or a Maeda sales service agency to request inspection and repair service as needed.
5.2 CONSUMABLES
Parts for mounting searcher hook are consumable items. Replace them at periodic inspection or before they
reach abrasion limits. Replace consumable items regularly, which will produce economical use of this machine.
Always replace with a Maeda genuine item. Check parts catalog for correct part number for parts request.
[CONSUMABLES LIST]
Part Replacement cycle
Searcher hook fix bolt
M12x35L strength 10.9 (4pcs)
Every 6 months or when damage, crack, or squash is found
Searcher hook fix bolt
M12x30L strength 10.9 (4pcs)
Every 6 months or when damage, crack, or squash is found
Searcher hook fix bolt
M8x16L strength 10.9 (1pcs)
Every 6 months or when damage, crack, or squash is found
Searcher hook fix nut
M12x1grade (8pcs)
Every 6 months or when damage, crack, or squash is found
Searcher hook fix washer
M12x3.2t (high tension)(8pcs)
Every 6 months or when damage, crack, or squash is found
Items include a halt period. Contact Maeda or a Maeda sales service agency for part replacement information.
