5.2 RATED TOTAL LOAD CHART FOR SEARCHER HOOK
Rated total load Chart
5.945m BOOM 8.145m BOOM 10.315m BOOM 12.485m BOOM
Working
radius (m)
Rated total
load (kg)
Working
radius (m)
Rated total
load (kg)
Working
radius (m)
Rated total
load (kg)
Working
radius (m)
Rated total
load (kg)
2.50
or less
300
2.70
or less
300
4.00
or less
300
4.50
or less
300
3.00 300 3.00 300 4.50 300 5.00 300
3.50 300 3.50 300 5.00 300 6.00 300
4.00 300 4.00 300 6.00 300 7.00 250
4.50 300 4.50 300 7.00 300 8.00 200
5.00 300 5.00 300 8.00 300 9.00 200
5.62 300 5.50 300 9.00 300 10.00 150
-- -- 6.00 300 9.99 250 11.00 150
-- -- 7.00 300 -- -- 12.16 150
-- -- 7.82 300 -- -- -- --
