Magtrol Model DSP7000 Dynamometer Controller
Appendix B: Front Panel/Display Menu Flow Charts
APPENDICES
B.2.2.1
Dyno
B.2.2.1.1
Max Power
SHIFT
MAXPOWER
0.000 -99,999
B.2.2.1.2
Dynamometer
SHIFT
DYNAMOMETER
TSC1/TSC2
HD
WB
PB
TM/TF
HD5
Note:
Refer to flo
w charts B.3.1.1 through B.3.1.5 for a more detailed
breakdo
wn based on test instrument selection.
All flow charts will
be a continuation of B.2.2.1.2 beginning at SHIFT*.
B.2.2.1.3
Encoders
ENCODERS
SHIFT
SPEED
ALARMS
0-200,000
SOURCE
QUAD DEG
TACH A
AI 1
PULSES/REV
1-99,999
DEGREES
10-90
134
136
