HYDRAULIC SYSTEM 16000 SERVICE/MAINTENANCE MANUAL
2-30
Published 05-09-17, Control # 014-28
P1537a
Item Description
1 Port A Multi-Function Valve
2 Port B Multi-Function Valve
3Protective Cap
4 Lock Nut
5 Adjusting Screw
6Bypass Hex
Wrench Size
Pump Size
Lock Nut
Hex Size
Internal
Hex Size
Series 042 -100 Units 19 mm 5 mm
Series 130 Units
13 mm
or
24 mm
4 mm
or
8 mm
Multi-Function Valve
A1161
FIGURE 2-28
1
4
6
1
3 (5 under)
2
2
Typical Pump Installation
FIGURE 2-29
Typical Diagnostic Screen
(Screen for Drum 4 Shown)
Handle
Command
Drum
Speed
System
Pressure
Pump
Command
16-1013
