ELECTRIC SYSTEM 16000 SERVICE/MAINTENANCE MANUAL
3-22
Published 05-09-17, Control # 014-28
74-P DO-16 Right Front Jacking Cylinder Retract 0 Volts Off; 24 Volts On CAN28-2-128
74-R DO-15 Right Front Jacking Cylinder Extend 0 Volts Off; 24 Volts On CAN28-2-64
74-S DO-18 Right Rear Jacking Cylinder Retract 0 Volts Off; 24 Volts On CAN28-3-2
74-T Ground Left Wheel Steering Clockwise Ground
74-U DO-19 Left Wheel Steering Clockwise 0 Volts Off; 24 Volts On CAN28-3-4
74-V Ground Left Wheel Steering Counter-Clockwise Ground
74-W DO-20 Left Wheel Steering Counter-Clockwise 0 Volts Off; 24 Volts On CAN28-3-8
74-X Ground Right Wheel Steering Clockwise Ground
74-Z DO-21 Right Wheel Steering Clockwise 0 Volts Off; 24 Volts On CAN28-3-16
74-a Ground Right Wheel Steering Counter-Clockwise Ground
74-b DO-22 Right Wheel Steering Counter-Clockwise 0 Volts Off; 24 Volts On CAN28-3-32
74-c Ground Left Wheel Brakes Ground
74-d DO-23 Left Wheel Brakes 0 Volts Off; 24 Volts On CAN28-3-64
74-e Ground Right Wheel Brakes Ground
74-f DO-24 Right Wheel Brakes 0 Volts Off; 24 Volts On CAN28-3-128
74-g Ground Jumper to Node Select 1 and 3 Ground
74-h NS1 Node Select 1 Jumper to Ground
74-k NS-3 Node Select 3 Jumper to Ground 0 Volts (With Jumper)
W76 Receptacle – Telescopic Beam, Steering Encoder, and Jacking Limits
76-A Ground Jumper to Node Select 1 and 3 Ground
76-B DO-7 Telescopic Beam Cylinder Extend 0 Volts Off; 24 Volts On CAN28-1-64
76-C Ground Telescopic Beam Cylinder Extend and Retract Ground
76-D DO-8 Telescopic Beam Cylinder Retract 0 Volts Off; 24 Volts On CAN28-1-128
76-E Ground MAX-ER Tray Level Sensor Ground
76-F DO-9 Telescopic Beam Hinge Pin In 0 Volts Off; 24 Volts On CAN28-2-1
76-G Ground Telescopic Beam Hinge Pin In and Out Ground
76-H DO-10 Telescopic Beam Hinge Pin Out 0 Volts Off; 24 Volts On CAN28-2-2
76-J DI-8 Left Rear Jacking Cylinder Limit 0 Volts Off; 24 Volts On CAN51-1-128
76-K NS-1 Node Select 1 Jumper to Ground 0 Volts (With Jumper)
76-M NS-3 Node Select 3 Jumper to Ground 0 Volts (With Jumper)
76-P DI-7 Left Front Jacking Cylinder Limit 0 Volts Off; 24 Volts On CAN51-1-64
76-R 24 Volts Left Front and Rear Jacking Cylinder Limit 24 Volts Nominal
76-S 24 Volts MAX-ER Tray Level Sensor 24 Volts Nominal
76-T 24 Volts Right Front and Rear Jacking Cylinder Limit 24 Volts Nominal
76-U Ground Right Front and Rear Jacking Cylinder Limit Ground
76-W Ground Left Front and Rear Jacking Cylinder Limit Ground
76-a AI-9 MAX-ER Tray Level Sensor 0 to 10 VDC Roll CAN18-2 *1
76-b AI-10 MAX-ER Tray Level Sensor 0 to 10 VDC Pitch CAN18-4 *1
76-c AI-11 Right Front Jacking Cylinder Limit 0 Volts Off; 24 Volts On CAN18-6 *1
76-d AI-12 Right Front and Rear Jacking Cylinder Limit 0 Volts Off; 24 Volts On CAN18-8 *1
76-g 24 Volts Left Wheel Steering Encoder 24 Volts Nominal
76-j Ground Left and Right Wheel Steering Encoder Ground
76-m 24 Volts Right Wheel Steering Encoder 24 Volts Nominal
