Manitowoc Published 05-09-17, Control # 014-28 7-15
16000 SERVICE/MAINTENANCE MANUAL POWER TRAIN
7
FIGURE 7-12
Bleed Screw
81013188
Cooler Drain
Valve
FIGURE 7-13
Bleed Valve
Bleed Screw
Bleed Screw
Deaeration Tank
Fill Cap
Cooling Fins
Bleed Screw
