Item Description Item Description
1 Filter 2 (in tank return)(2 or 3 each) 7a Shut-Off Valve Handle
2a Fill Plug (manual fill port) 7b Locking Pin
2b Power-Fill Coupling 8 Hydraulic Tank Drain Valve
3 Breather 9 Vent Cap (2 in charge pressure manifold) past production only
4a Air Valve (for venting air) 10 Vent Cap (1 in suction manifold)
4b Coupler 11 Vent Cap (1 in suction line at accessory pump)
5 Access Cover (past production shown) 12 Bleed Port for Initial Fill (16001142 and newer)
6 Filter 1 (charge filter assembly 2 each) 13 Heater (240V here if equipped)
FIGURE 2-1
10
9
1
View D
View C
View E
View F
View A
P2295
P2509
P2250
P2251
P2294
2a
2b
6 (Filters 1)
Past Production have Vent Plugs.
Filters omitted on 16001142 and newer.
4a
P2248
View B
3
Past Production shown
16001142 and newer similiar
Past Production shown.
Located on bottom of tank
on 16001142 and newer.
5
11
4b
8
13
