1.5 Technical data
1 - 12 3 112 xxx en Operating Manual GMK6300L
xx.xx.xxxx
Auxiliary hoist
Main boom
Counterweight
parts
The stability of the crane rigged with the counterweight sections delivered
has been tested.
Name
Length x width x height
in m (ft)
Weight
in kg (lbs)
Complete auxiliary hoist 1.15 x 1.90 x 0.80
(3.77 x 6.23 x 2.62)
2,000
(4,410)
Rigging frame 1.43 x 2.17 x 0.55
(4.69 x 7.12 x 1.80)
352
(776)
Name Length x width x
height in m (ft)
Weight in kg (lbs)
Complete main boom 16.0 x 2.0 x 2.0
(52.5 x 6.6 x 6.6)
27,500
(60,630)
Name
Length x width x
height in m (ft)
Weight
in kg
1)
(lbs)
7 t base plate 2.99 x 2.42 x 1.25
(9.81 x 7.94 x 4.10)
7,000
(15,440)
each 9.5 t plate 2.99 x 2.40 x 0.29
(9.81 x 7.87 x 0.95)
9,500
(20,950)
9.5 t section with cutouts 2.99 x 2.40 x 0.24
(9.81 x 7.87 x 0.79)
9,500
(20,950)
each 9 t block 1.39 x 1.44 x 1.24
(4.56 x 4.72 x 4.07
9,000
(19,850)
each 10 t block 0.97 x 1.97 x 1.30
(3.18 x 6.46 x 4.27
10,000
(22,050)
1)
There may be deviations of up to ± 3% due to the manufacturing
procedure.
