Rigging work
12.7 Rigging/unrigging the counterweight
12 - 72 3 112 xxx en Operating Manual GMK6300L
xx.xx.xxxx
The diagram shows all counterweight sections in version B with additional
equipment (8) and (9) with the maximum counterweight mass of 92.5 t
(203,928 lbs).
The base plate (1) must always be at the bottom.
The counterweight section (3) must lie on the right-hand side and the
counterweight section (4) on the left-hand side of the base plate (1), as
viewed in the direction of travel.
The counterweight section (2) must lie between the counterweight
sections (3) and (4).
The counterweight section (5) must lie on top of the counterweight
sections (2), (3) and (4).
The counterweight sections (6) can be exchanged among each other.
The counterweight section (7) must always be placed on top for counter-
weight combinations from 54.5 t (120,152 lbs).
The counterweight blocks (8) can only be attached to the counterweight
section (7).
The counterweight blocks (9) can only be attached to the counterweight
blocks (8).
