Grove Published 3-22-2021, Control # 702-02 3-29
GRT8120 OPERATOR MANUAL OPERATING CONTROLS AND FEATURES
3
FOOT PEDAL CONTROLS AND FLOOR MAT
The foot pedal controls (Figure 3-14) include the swing brake
pedal, service brake pedal, and throttle pedal.
FIGURE 3-14
Item Description Page
1 Swing Brake Pedal 3-30
2 Service Brake Pedal 3-30
3 Throttle Pedal 3-30
4 Floor Mat 3-30
9838-13
3
21
4
