OPERATING PROCEDURES GRT8120 OPERATOR MANUAL
4-80 Published 3-22-2021, Control # 702-02
Crane Status Area
The following indicators make up the Crane Status Area
(Figure 4-71) of the ODM Main Screen.
Item Description
1 Parking Brake Indicator
2 Marker Light/Headlight Indicator
3 Suspension Control Indicator
4 Economy (ECO) Mode Indicator
5 Two-Wheel Drive/Four-Wheel Drive Indicator
6 Working Range Limiter (WRL) Indicator
FIGURE 4-71
1 2
6
5
4
10254-39a
3
