GRT8120 OPERATOR MANUAL OPERATING CONTROLS AND FEATURES
RIGHT LOWER CONTROL PANEL
The right lower control panel (Figure 3-5) includes the
turntable swing lock pin control handle, 12-volt outlet, and
on-board diagnostic (OBD) connector.
FIGURE 3-5
Item Description Page
1 Turntable Swing Lock Pin Control Handle 3-16
2 12-Volt Outlet 3-16
3 Engine On-Board Diagnostic (OBD) Connector 3-16
9838-9
1
3
2
