GRT8120 OPERATOR MANUAL OPERATING CONTROLS AND FEATURES
3
RATED CAPACITY LIMITER DISPLAY
MODULE AND OPERATOR DISPLAY
MODULE
The Rated Capacity Limiter Display Module (RDM) and the
Operator Display Module (ODM) (Figure 3-6) are located to
the right of the steering column.
Each module consists of a display screen, navigation control
pad, warning indicators, screen brightness sensor, and USB
diagnostic connector.
Item Description Page Item Description Page
1 Rated Capacity Limiter Display Module (RDM) 3-18 6 RCL Early Warning Indicator 3-19
2 Operator Display Module (ODM) 3-18 7 Anti-Two-Block (A2B) Indicator 3-19
3 Navigation Control Pad 3-18 8 Swing Brake Engaged Indicator 3-19
4 USB Diagnostic Connector 3-19 9 Brightness Sensor 3-19
5
RCL Shutdown Warning Indicator (Non-CE
Certified Cranes)
3-19 10 Internal Temperature Warning Indicator 3-19
5
RCL Shutdown Warning Indicator (CE Certified
Cranes)
3-19
9838-10
FIGURE 3-6
2
1
7
8
4
9
10
4
6
3
3
9
5
10
