Active Screen Indicator Area
The following indicator can appear in the Active Screen
Indicator Area (1, Figure 4-69) of the ODM Main Screen:
Name Symbol Description
Active Screen Indicator
Indicates the ODM screen is being controlled by the Jog Dial.
Refer to Navigating the Operator Display Module and Rated Capacity Limiter
Display Module, page 4-67.
FIGURE 4-69
1
10254-39a
