Manitowoc Grove GRT8120 - Disconnecting the Hydraulic Connection

5-54 Published 3-22-2021, Control # 702-02
SET-UP AND INSTALLATION GRT8120 OPERATOR MANUAL
Disconnecting the Hydraulic Connection
1. Remove the hose lines (2, Figure 5-77) from the
connections (1).
2. Close off the hose lines and the connections (1) with the
protective caps.
3. Secure hoses in holder (3) on the boom extension base
section.
7567-38
1
2
3
FIGURE 5-77
