OPERATING CONTROLS AND FEATURES GRT8120 OPERATOR MANUAL
3-38 Published 3-22-2021, Control # 702-02
RIGHT WINDOW AND SKYLIGHT WINDOW
The right window and skylight window (Figure 3-19) can be
opened for ventilation. The skylight sun shade can be
adjusted to multiple positions to allow varying amounts of
light into the cab.
FIGURE 3-19
9838-17
Item Description Page
1 Skylight Window Latch (If Equipped) 3-39
2 Skylight Sun Shade 3-39
3 Right Side Window Latch 3-39
1
3
2
