OPERATING CONTROLS AND FEATURES GRT8120 OPERATOR MANUAL
3-44 Published 3-22-2021, Control # 702-02
120V/240V Engine Block Heater and Outlet
The crane is equipped with a 120V engine block heater for
cold weather operation.
The electrical outlet (1, Figure 3-25) for connecting power to
the engine block heater is located on the left side of the
crane near the battery disconnect switch.
An optional 240V engine block heater and outlet is available
in place of the 120V version.
Emergency Stop Buttons (Optional)
The optional Emergency Stop Buttons (1, Figure 3-26) are
located on the left and right sides of the carrier.
Push in the red button to stop the engine and all crane
functions.
When the Emergency Stop Button is pushed in, the
Emergency Stop Active Alert in the Alerts Area (Figure 4-68)
of the Operator Display Module (ODM) comes on (red).
Rotate and pull out button to allow the engine to be re-started
and resume normal operation.
